1P 16AX 2-way switch white - 20005.B

Pdf

Vimar - 20005.B - 1P 16AX 2-way switch white

20005.B
Wiring devices / Traditional wiring devices / EIKON / Devices

1P 16AX 2-way switch white
1P 16 AX 250 V~ 2-way switch, lightable, replaceable button, white. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9016

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
22,30 mm

Device height
49,00 mm

Device depth
35,90 mm

Built-in depth
25,00 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

13. SNI - Indonesia

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

34. PSE - Japan

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

50. Product Environm. Profile

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352316362

1 NR

4.1x2.8x5.3 [cm]

28.73 [g]

8007352316379

50 NR

21.4x11.6x14.2 [cm]

1,497 [g]

8007352352117

500 NR

57.5x22.5x30 [cm]

15,810 [g]

8007352750722

10,500 NR

120x80x105 [cm]

332,010 [g]
