1P 16AX 2-way switch Next - 20005.N

Pdf
20005.N

Eikon Next / Devices / Basic devices

1P 16AX 2-way switch Next
1P 16 AX 250 V~ 2-way switch, lightable, replaceable button, Next. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

Class group
Domestic switching devices
Class
Switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module syst
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (akin)
9022
Label space/information surfac
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
Not included
Suitable for degree of protect
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
35,90 mm
Built-in depth
25,00 mm
最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352285675
1 NR
4.1x2.8x5.3 [cm]
28.6 [g]
Barcode Qty 50 NR
8007352285682
50 NR
21.4x11.6x14.2 [cm]
1,527.93 [g]
Barcode Qty 500 NR
8007352352094
500 NR
57.5x22.5x30 [cm]
15,772.67 [g]
