Three 1P 20AX 2-way switches grey - 20007

Pdf
Vimar - 20007 - Three 1P 20AX 2-way switches grey
Vimar - 20007 - Three 1P 20AX 2-way switches grey
20007

Eikon / Devices / Basic devices

Three 1P 20AX 2-way switches grey
Three 1P 20 AX 250 V~ 2-way switches, grey - 2 modules. Max 250 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
3
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
20,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
42,75 mm
Built-in depth
31,60 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

15. CCC - China

19. NOM - Mexico

31. TISI - Thailand

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352404465
1 NR
5.1x4.3x5.3 [cm]
71.45 [g]
Barcode Qty 20 NR
8007352404472
20 NR
26.9x11.6x9 [cm]
1,510 [g]
