2P 45A 1-way switch COOKER 5M grey - 20019.CK

20019.CK

Eikon / Devices / Basic devices

2P 45A 1-way switch COOKER 5M grey
2P 45 A 250 V~, 1-way switch, lightable, COOKER symbol, with built-in frame for installation in British standard mounting boxes, to complete with 5-module British standard cover plate, grey. Max 200 W for integrated ballast lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices
Class
Switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module syst
5
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Screw mounting
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (akin)
7024
Label space/information surfac
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
Not included
Suitable for degree of protect
IP40
Nominal voltage
250 v
Rated current
45 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
82,50 mm
Height of device
144,00 mm
Depth of device
33,00 mm
Built-in depth
22,50 mm
最小订单数量: 5 NR

条形码

8007352406865
1 NR
8.5x3.5x15 [cm]
142.6 [g]
8007352406872
5 NR
17.5x16.3x9.8 [cm]
795.8 [g]
