Vimar - 20022.L.N - Button 2M light symbol Next

20022.L.N
Wiring devices / Traditional wiring devices / EIKON / Buttons

Button 2M light symbol Next
Interchangeable 2-module button, lightable light symbol, Next

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Control element/cover plate for domestic switching devices

Model
One-part rocker

Imprint/indication
Symbol ˝light˝

Utilization
Switch/push button

Suitable for touch sensor connector for bus system
No

Type of fastening
Clamp mounting

Monitoring window/light outlet
Yes

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Lacquered

Surface finishing
Matt

Colour
Silver

RAL-number (similar)
9022

With label area
No

With exchangeable lens/symbol
No

Suitable for degree of protection (IP)
IP40

Depth
1.115,00 mm

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 2 NR

条形码

8007352285057

1 NR

4.46x4.9x2.29 [cm]

8.33 [g]

8007352285064

2 NR

5.1x2.8x5.3 [cm]

20.6 [g]

8007352730847

20 NR

14.4x11.6x6 [cm]

206 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
