Blank module Next - 20041.N

Pdf
Vimar - 20041.N - Blank module Next
Foto gallery #1
Foto gallery #2
Vimar - 20041.N - Blank module Next

20041.N
Wiring devices / Traditional wiring devices / EIKON / Blank module

Blank module Next
Blank module, Next

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Push button
Method of operation
Other
Number of modules (module system)
100
Nominal voltage
0 V
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Mounting with claw
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Label space/information surface
Yes
Device width
22,30 mm
Device height
49,00 mm
Device depth
20,50 mm

01. IMQ - Italy

08. ASTA - UK

15. CCC - China

29. QCERT - Colombia

50. Product Environm. Profile

96. Electrotechnical expert

最小订单数量: 100 NR

条形码

Barcode Qty 1 NR
8007352284654
1 NR
2.2x4.9x2 [cm]
5 [g]
Barcode Qty 10 NR
8007352286146
10 NR
22x4.9x2 [cm]
51.33 [g]
Barcode Qty 100 NR
8007352284661
100 NR
28.2x11.1x10 [cm]
606.73 [g]
Barcode Qty 1,000 NR
8007352352148
1,000 NR
57.5x22.5x30 [cm]
6,611.33 [g]
Barcode Qty 21,000 NR
8007352352414
21,000 NR
80x120x103 [cm]
150,000 [g]
