2P 10AX 2-way switch white - 20060.B

Pdf
20060.B

Eikon white / Devices / Devices - other functions

2P 10AX 2-way switch white
2P 10 AX 250 V~ (6 terminals) two-button switch, with directional arrows and central OFF position, white. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Other
Contacts
2 change-over contacts
Number of poles
2
Feedback-signal contact
No
Number of rockers
1
Number of modules (module syst
1
With lighting
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (akin)
9016
Transparent
No
Label space/information surfac
Yes
Suitable for degree of protect
IP40
Nominal voltage
250 v
Rated current
10,00 A
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
43,50 mm
最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352315655
1 NR
5.1x2.8x5.3 [cm]
43.33 [g]
Barcode Qty 10 NR
8007352315662
10 NR
14.4x11.6x6 [cm]
479.47 [g]
Barcode Qty 120 NR
8007352637849
120 NR
36.5x33x13.5 [cm]
6,180 [g]
问题: Can the product be fully opened by pressing the push button once?
回答: Yes. Upon pressure, the product even remains on after you release it, allowing the continuous closure of the circuit to which it is connected without having to hold it down.
