MASTER dimmer 120V white - 20135.1.120.B

Pdf
Vimar - 20135.1.120.B - MASTER dimmer 120V white
Vimar - 20135.1.120.B - MASTER dimmer 120V white
20135.1.120.B

Eikon white / Devices / Electronic devices

MASTER dimmer 120V white
Universal-dimmer 120 V~ 60 Hz, phase-cutting, for: 40-400 W incandescent lamps, 40-300 VA electronic transfomers, 10-200 W CFL lamps, 3-200 W LED lamps and LED phase-cutting electronic transfomers, ON/OFF control and built-in or from NO peripheral push buttons regulation, MASTER function for 20137.120, minimum brightness regulation, visible in darkness, white. Not for Isoset enclosures

产品状态
3 - Active

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Push button
Type of load
Universal and LED Retrofit
Applicable with button
Yes
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush-mounted
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
120,00 - 120,01 V
Frequency
60,00 - 60,01 HZ
Control voltage
120,00 - 120,01 V
Connection type
Screwed terminal
Device width
22,30 mm
Device height
49,00 mm
Device depth
50,70 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352576087
1 NR
5.1x4.3x5.3 [cm]
58.3 [g]
Barcode Qty 10 NR
8007352576094
10 NR
26.9x11.6x4.9 [cm]
646.3 [g]
