Switched 2P+E 13A English outlet white - 20221.L.B

Pdf
Vimar - 20221.L.B - Switched 2P+E 13A English outlet white
Vimar - 20221.L.B - Switched 2P+E 13A English outlet white

20221.L.B
Wiring devices / Traditional wiring devices / EIKON / Devices

Switched 2P+E 13A English outlet white
2P+E 13 A 250 V~ SICURY socket outlet, English standard, 2P 1-way switch, indicator unit, with built-in mounting frame for 3-module British standard installation, white

产品状态
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
British Standard
Number of units
2
Number of modules (module system)
3
Number of socket outlets switchable
1
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9016
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
Yes
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
With miniature fuse
No
Mounting method
Flush-mounted
Type of fastening
Mounting with screw
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
Yes
Rotated central insert
No
Nominal current
13 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
82,50 mm
Device height
82,50 mm
Device depth
29,50 mm

00. CE Marking - EU

08. ASTA - UK

30. G-Mark - Gulf Countries

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

99. WEEE Directive

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352389120
1 NR
8.5x3.9x8.6 [cm]
105.6 [g]
Barcode Qty 10 NR
8007352389137
10 NR
20.7x18.5x9.6 [cm]
1,156 [g]
Barcode Qty 60 NR
8007352642362
60 NR
39x29.5x22 [cm]
7,426 [g]
