Vimar - 20365.N - 9P SUB D socket connector Next

20365.N
Wiring devices / Traditional wiring devices / EIKON / Devices

9P SUB D socket connector Next
9-pin socket connector, SUB D, soldering, Next - 2 modules

产品状态
2 - Will be discontinued

图纸

PNG DXF

Class group
Domestic switching devices

Class
Insert/cover for communication technology

Assembly arrangement
Modular device for domestic switching devices

Utilization
D-sub-miniature

Support ring
No

With dust cover
No

With hinged lid
No

With imprint
No

Mounting method
Flush-mounted

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Lacquered

Surface finishing
Matt

Colour
Silver

RAL-number (similar)
9022

Transparent
No

Number of modules (module system)
2

With strain relief
No

Luster terminal
No

Suitable for degree of protection (IP)
IP20

Device width
44,80 mm

Device height
49,00 mm

Device depth
20,10 mm

00. CE Marking - EU

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 5 NR

条形码

8007352289864

1 NR

5.1x2.8x5.3 [cm]

20.33 [g]

8007352289871

5 NR

14.2x6.7x5.9 [cm]

134.47 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
