20606.0

Eikon / Mounting frames / For square boxes

Frame 1M BS no blank module
Frame 1M BS no blank module

产品状态
3 - Active

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush mounted (plaster)

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
1

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
Yes

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for floor box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Metal

Material quality
Other

01. IMQ - Italy

37. Marking - Morocco

最小订单数量: 10 NR

8007352623002

1 NR

8.2x8.2x2.3 [cm]

43.905 [g]

8007352623019

2 NR

8.5x8.5x4.8 [cm]

80.8 [g]

8007352623026

40 NR

29.5x24.8x8.7 [cm]

1,756.2 [g]

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
