Two 2P+E 15A USA outlet with GFCI grey - 21296

Pdf
21296

Eikon EVO / Devices / Protected socket outlets

Two 2P+E 15A USA outlet with GFCI grey
Double 2P+E 15 A 125 V~ 60 Hz socket outlet, American standard with GFCI , built-in mounting frame, to complete with 3-module cover plate, grey

产品状态
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
American National Standard
With built-in USB power supply
No
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
No
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7024
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
Yes
With orientation lighting
No
Over voltage protection
No
Fault current protection
Yes
With miniature fuse
No
Mounting method
Flush mounted (plaster)
Type of fastening
Mounting with screw
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
125 v
Frequency
60,00 - 60,01 HZ
Rated fault current
6 mA
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
73,00 mm
Height of device
107,00 mm
Depth of device
41,10 mm

00. CE Marking - EU

19. NOM - Mexico

37. Marking - Morocco

最小订单数量: 5 NR

条形码

Barcode Qty 1 NR
8007352503311
1 NR
6.7x5.2x12 [cm]
148.5 [g]
Barcode Qty 5 NR
8007352503328
5 NR
29.5x13.5x7.7 [cm]
844.1 [g]
Barcode Qty 95 NR
8007352503335
95 NR
54.5x37x28.5 [cm]
16,914 [g]
