21613
Wiring devices / Traditional wiring devices / EIKON / Mounting frames
Frame 3M +screws
3-module mounting frame, with screws, for 3-module mounting boxes
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Mounting method
Mounting with screw
Mounting with screw
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
3
3
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
00. CE Marking - EU
00. CE Marking - EU
00. CE Marking - EU
00. CE Marking - EU
29. QCERT - Colombia
50. Product Environm. Profile
最小订单数量: 200 NR
条形码
8007352416345
1 NR
10.7x7.3x1.9 [cm]
41.5 [g]
8007352416352
10 NR
10.7x7.3x19 [cm]
416.7 [g]
8007352784253
180 NR
44.5x23.5x23.5 [cm]
7,470 [g]
8007352417748
200 NR
39.5x29.5x23 [cm]
8,016 [g]
8007352483026
6,400 NR
80x120x106 [cm]
280,768 [g]
| 问题： | I purchased an EikonEvo support module, can I install a plaque from the Eikon series? |
|---|---|
| 回答： | No, each series has its own support module with corresponding plaques. |
