Vimar - 21614 - Frame 4M +screws

21614

Eikon / Mounting frames / For rectangular boxes

Frame 4M +screws
4-module mounting frame, with screws, for 4-module mounting boxes

产品状态
3 - Active

您可能也感兴趣

21614.C - Cover 4M Eikon mount-frame

07937 - Screw for frame fixing - 35mm

07939 - Screw for frame fixing - 50 mm

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush mounted (plaster)

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
4

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
Yes

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for floor box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

01. IMQ - Italy

01. IMQ - Italy

01. IMQ - Italy

15. CCC - China

29. QCERT - Colombia

37. Marking - Morocco

96. Electrotechnical expert

最小订单数量: 10 NR

条形码

8007352420045

1 NR

13x7.3x1.9 [cm]

40.9 [g]

8007352420052

10 NR

13x7.3x19 [cm]

412.2 [g]

8007352420069

100 NR

39.5x29.5x14.5 [cm]

4,473 [g]

8007352483040

4,000 NR

80x120x86.5 [cm]

191,200 [g]
