Frame 7M +screws - 21617

Pdf

21617
Wiring devices / Traditional wiring devices / EIKON / Mounting frames

Frame 7M +screws
7-module mounting frame, with screws, for 6/7-module mounting boxes

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
7
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic
最小订单数量: 30 NR

条形码

Barcode Qty 1 NR
8007352421509
1 NR
19.7x7.3x1.9 [cm]
55.86 [g]
Barcode Qty 30 NR
8007352421516
30 NR
28.4x24.4x14.9 [cm]
1,830 [g]
Barcode Qty 120 NR
8007352626010
120 NR
60x33x27.5 [cm]
7,740 [g]
