Frame 8M with screws - 21618

Pdf

21618
Wiring devices / Traditional wiring devices / EIKON / Mounting frames

Frame 8M with screws
8 (4+4)-module mounting frame, with screws, for V71318 and V71718 flush and 20788 table mounting boxes

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
4
Number of modules vertical (module system)
2
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic
最小订单数量: 5 NR

条形码

Barcode Qty 1 NR
8007352425545
1 NR
14x14.4x1.7 [cm]
53.7 [g]
Barcode Qty 5 NR
8007352425552
5 NR
17.5x16.3x9.8 [cm]
359.4 [g]
