Plate 6M (2+2+2) 71mm silver ice - 21644.72

Pdf

21644.72
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Plate 6M (2+2+2) 71mm silver ice
6-module cover plate (2+2+2, 71 mm distance between centres), bevelLED crystal, silber ice

产品状态
3 - Active

您可能也感兴趣

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
6
Mounting direction
Horizontal and vertical
Number of units horizontal
6
Number of units vertical
1
Number of modules horizontal (module system)
6
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Glass
Material quality
Glass
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9023
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
95,40 mm
Height
237,40 mm
Depth
9,60 mm
Built-in width
95,40 mm
Built-in height
237,40 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

15. CCC - China

29. QCERT - Colombia

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352435681
1 NR
27.1x11.4x3.2 [cm]
274.8 [g]
Barcode Qty 25 NR
8007352444157
25 NR
38x34x24 [cm]
7,400 [g]
