1P 10AX 2-way switch Vintage satin gold - 22004.88

Pdf

Vimar - 22004.88 - 1P 10AX 2-way switch Vintage satin gold

22004.88
Wiring devices / Traditional wiring devices / EIKON / Devices

1P 10AX 2-way switch Vintage satin gold
1P 10 AX 250 V~ Vintage 2-way switch, satin-finish gold. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
230 V

Rated current
10,00 A

With lighting
No

With signal lamp
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Metal

Material quality
Brass

Anti-bacterial treatment
No

Surface protection
Lacquered

Surface finishing
Matt

Colour
Gold

RAL-number (similar)
1035

Transparent
No

Label space/information surface
Yes

Device width
22,30 mm

Device height
44,80 mm

Device depth
54,70 mm

00. CE Marking - EU

01. IMQ - Italy

09. VDE - Germany

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352655355

1 NR

5.1x6.5x2.7 [cm]

33.3 [g]

8007352655362

10 NR

14.5x11x7.4 [cm]

381.3 [g]

分享

Codice QR scheda articolo

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
