Axial 1P NO 10A push button mechan.Flat

Pdf

Vimar - 22108 - Axial 1P NO 10A push button mechan.Flat

22108
Wiring devices / Traditional wiring devices / EIKON / Devices

Axial 1P NO 10A push button mechan.Flat
Axial 1P NO 10A push button mechan.Flat

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Basic element with housing top

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Rated current
10,00 A

With lighting
Yes

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Transparent
No

Label space/information surface
Yes

Device height
49,00 mm

Device depth
43,70 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

20. IQC - Argentina

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352621404

1 NR

5.1x2.8x5.3 [cm]

27.4 [g]

8007352621411

10 NR

14.4x11.6x6 [cm]

321 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
