Plate 3Mx1 Vintage satin gold - 22673.1.88

Pdf

22673.1.88
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Plate 3Mx1 Vintage satin gold
3-module cover plate for a Vintage control, metal, satin-finish gold. Install the blank modules 21041 in the slots where there are no devices

产品状态
3 - Active

图纸

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
1
Mounting direction
Horizontal and vertical
Number of units horizontal
1
Number of units vertical
1
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Surface protection
Lacquered
Surface finishing
Matt
Colour
Gold
RAL-number (similar)
1036
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
122,00 mm
Height
90,00 mm
Depth
7,15 mm
Built-in height
90,00 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352655584
1 NR
12.5x9.5x1.4 [cm]
216.6 [g]
Barcode Qty 5 NR
8007352655591
5 NR
13.5x8x10.4 [cm]
1,134 [g]
