Axial 1P 10AX 1-way switch mechanism 2M - 30000.2

Pdf
Vimar - 30000.2 - Axial 1P 10AX 1-way switch mechanism 2M
Vimar - 30000.2 - Axial 1P 10AX 1-way switch mechanism 2M

30000.2
Wiring devices / Traditional wiring devices / LINEA / Devices

Axial 1P 10AX 1-way switch mechanism 2M
1P 10 AX 250 V~ lightable 1-way switch mechanism, to be completed with 2-module button - 2 modules. Max 100 W for lamps with built-in power supply unit (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

31000S.2B
31000S.2B - Lower 2M path light button white
31000S.2G
31000S.2G - Lower 2M path light button black
31000S.2C
31000S.2C - Lower 2M path light button canvas
31000A.2B
31000A.2B - Axial button 2M white
31000A.2G
31000A.2G - Axial button 2M black
31000A.2C
31000A.2C - Axial button 2M Canvas
31000.2B
31000.2B - Button 2M white
31000.2G
31000.2G - Button 2M black
31000.2C
31000.2C - Button 2M Canvas
00943.W
00943.W - Linea 110-250V white LED unit

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
No
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
Black
RAL-number (similar)
7021
Label space/information surface
No
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Impact strength
Other
Nominal voltage
250 V
Rated current
10,00 A
Switching current for fluorescent lamps
10
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Device width
44,70 mm
Device height
49,10 mm
Device depth
36,00 mm
Built-in depth
32,30 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352714724
1 NR
5.2x4.3x5.6 [cm]
35.68 [g]
Barcode Qty 20 NR
8007352714731
20 NR
23x11.2x12.8 [cm]
809.4 [g]
Barcode Qty 120 NR
8007352714748
120 NR
35x25x24 [cm]
5,200 [g]
