1P 10AX 2M 1-way switch in-line black - 30000.2G

Pdf
Vimar - 30000.2G - 1P 10AX 2M 1-way switch in-line black
Vimar - 30000.2G - 1P 10AX 2M 1-way switch in-line black

30000.2G
Wiring devices / Traditional wiring devices / LINEA / Devices

1P 10AX 2M 1-way switch in-line black
1P 10 AX 250 V~ lightable aligned 1-way switch, replaceable button, black - 2 modules. Max 100 W for lamps with built-in power supply unit (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

30004.2G
30004.2G - 1P 10AX 2M 2-way switch in-line black
30008.2G
30008.2G - 1P NO 10A button 2M black
30012.2G
30012.2G - 1P 10AX revers.switch 2M in-line black
00943.W
00943.W - Linea 110-250V white LED unit

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
No
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
Black
RAL-number (similar)
7021
Label space/information surface
No
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Impact strength
Other
Nominal voltage
250 V
Rated current
10,00 A
Switching current for fluorescent lamps
10
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Device width
44,60 mm
Device height
52,70 mm
Device depth
40,70 mm
Built-in depth
32,30 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352681248
1 NR
5.2x4.3x5.6 [cm]
40.89 [g]
Barcode Qty 20 NR
8007352681255
20 NR
23x11.2x12.4 [cm]
914.6 [g]
Barcode Qty 120 NR
8007352681262
120 NR
35x25x27.5 [cm]
5,826 [g]
