30302.01C
Wiring devices / Traditional wiring devices / LINEA / Devices
TV-RD-SAT single-conn.out.2outs canvas
TV-RD-SAT coaxial socket outlet, 5-2400 Mhz, single connection, demixed, 2 outputs with male connector (TV-RD) and female connector type F (SAT), 1 dB connection attenuation, canvas - 2 modules. Allows the passage of DC current and control signals (24 V 500 mA max)
产品状态
3 - Active
图纸
Class group
Antenna and satellite technique
Antenna and satellite technique
Class
Antenna socket box
Antenna socket box
Model
TWIN end socket
TWIN end socket
Type of socket outlet
TV/RD/SAT
TV/RD/SAT
Mounting method
Flush-mounted
Flush-mounted
Number of modules (module system)
1
1
Cover
None
None
Tap loss at 860 MHz
1,00 dB
1,00 dB
Tap loss at 2150 MHz
1,00 dB
1,00 dB
Number of outlets
2
2
Suitable for cable modem
No
No
TV frequency band
5 - 2.400 MHz
5 - 2.400 MHz
Suitable for remote power supply
Yes
Yes
Radio frequency band
5 - 2.400 MHz
5 - 2.400 MHz
SAT frequency band
5 - 2.400 MHz
5 - 2.400 MHz
Type of fastening
Snap mounting (engagement)
Snap mounting (engagement)
Colour
Beige
Beige
RAL-number (similar)
7032
7032
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Anti-bacterial treatment
No
No
Degree of protection (IP)
IP20
IP20
Device width
2.230,00 mm
2.230,00 mm
Device height
5.280,00 mm
5.280,00 mm
Device depth
3.920,00 mm
3.920,00 mm
00. CE Marking - EU
00. CE Marking - EU
37. Marking - Morocco
37. Marking - Morocco
最小订单数量: 10 NR
条形码
8007352689800
1 NR
4.6x2.7x5.6 [cm]
54.4 [g]
8007352689817
10 NR
14.6x10x6.6 [cm]
593.2 [g]
8007352689824
120 NR
31x22x21 [cm]
7,388.4 [g]
