Home autom.dial thermostat 2M white - 30471.B

Pdf

Vimar - 30471.B - Home autom.dial thermostat 2M white

30471.B
Smart systems&products / By-me Plus / LINEA / Devices

Home autom.dial thermostat 2M white
Home automation system dial thermostat for room temperature control (heating and air conditioning), 2- and 4-pipe system management, 3-speed and proportional fan coil control, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, can be interfaced with actuator with proportional analogue outputs 01466.1 to make a class V modulating room thermostat (contribution 3%), 1 input for wired temperature sensor 02965.1, white LED backlighting, white - 2 modules.

产品状态
3 - Active

单, 说明书, 文档

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Stats, switches and controllers

Class
Room thermostat

Model
Other

Type of power supply
Other

Connection
2-wire

With receiver
No

Measuring range
0 - 40 °C

External sensor
Yes

Thermal feedback
Parallel

Control characteristic
PID

Suitable for heating
Yes

Number of heater outputs
1

Suitable for cooling
Yes

Number of cooler outputs
1

Differential value
0,10 - 1,00 k

Adjustable differential
Yes

Temperature readable
Yes

With sound indicator
No

Sensor/feeler type
Resistance sensor

Mounting method
Flush-mounted

Number of modules (module system)
2

With display
Yes

Operation
Turn

With tap water circuit
No

Max. contact voltage
29 V

Max. contact load
0 A

Degree of protection (IP)
IP20

Degree of protection (NEMA)
Other

Explosion-proof
No

Colour
White

RAL-number
9016

Height
52,80 mm

Width
44,80 mm

Depth
41,70 mm

Diameter
0 mm

Class of the temperature control
V

Compatible with Apple HomeKit
Yes

Compatible with Google Assistant
Yes

Compatible with Amazon Alexa
Yes

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352689282

1 NR

6x5.4x5.2 [cm]

60.8 [g]

8007352689299

10 NR

28.1x13.1x6 [cm]

696.4 [g]

8007352689305

120 NR

38.5x29x30 [cm]

8,833 [g]
