Relay actuator 16A sensor black - 30474.G

Pdf
Vimar - 30474.G - Relay actuator 16A sensor black
Vimar - 30474.G - Relay actuator 16A sensor black

30474.G
Smart systems&products / By-me Plus / LINEA / Devices

Relay actuator 16A sensor black
Actuator with relay output 16 A 230 V ~ 50 Hz with integrated current sensor, black - 2 modules

产品状态
3 - Active

Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequent bidirectional
Yes
Mounting method
Flush-mounted
Width in number of modular spacings
1
Local operation/hand operation
Yes
With LED indication
Yes
Number of digital inputs
0
Suitable for C-load
Yes
Max. number of switching contacts
1
Max. switching current
16 A
Rated current
16 A
Rated operating voltage
230,00 - 230,01 V
Different phases connectable
No
With bus connection
Yes
Bus module detachable
No
Modular expandability
No
Degree of protection (IP)
IP40

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352688919
1 NR
6x5.4x5.2 [cm]
61.8 [g]
Barcode Qty 10 NR
8007352688926
10 NR
28.1x13.1x6 [cm]
618 [g]
