KNX IR detector white - 30575.B

Pdf
Vimar - 30575.B - KNX IR detector white
Vimar - 30575.B - KNX IR detector white

30575.B
Smart systems&products / KNX / LINEA / Devices

KNX IR detector white
Passive infrared motion detector, KNX standard, white - 2 modules

产品状态
3 - Active

Class group
Installation bus systems
Class
Movement sensor for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Movement sensor
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Transparent
No
With bus connection
Yes
Substation input
No
Creep-under protection
No
Operation mode switch
Yes
Animal zone
No
Staircase light controller
Yes
Response value luminosity adjustable
Yes
Teach-function for response value luminosity
No
Switch-off delay self-learning
No
DALI-2 certified
No
Max. reach sideways
10,00 m
Max. reach frontally
10 m
Diameter reach on floor
0 m
Detection angle vertical
0 - 36
Detection angle horizontal
0,00 - 112,00
Switching power
0 W

00. CE Marking - EU

27. KNX

37. Marking - Morocco

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352691803
1 NR
6x5.4x5.2 [cm]
44.65 [g]
Barcode Qty 10 NR
8007352691810
10 NR
28.1x13.1x6 [cm]
534 [g]
