Wiring devices / Traditional wiring devices / LINEA / Mounting frames
Frame 4M + screws
4-module mounting frame, with screws, for 4-module mounting boxes
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Type of fastening
Other
Other
With nail
No
No
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
4
4
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
最小订单数量: 10 NR
条形码
8007352697812
1 NR
14x7.8x1.9 [cm]
30 [g]
8007352697829
10 NR
14x12.5x7.8 [cm]
300 [g]
8007352784406
120 NR
38.5x30x17 [cm]
3,786 [g]
8007352795921
4,800 NR
120x80x105 [cm]
151,440 [g]
