30803.B
Wiring devices / View Wireless wiring devices / LINEA / Devices
16A IoT connected actuator white
View Wireless connected electronic control device with NO 16(3,5)A 100-240 V~ 50/60 Hz relay output, local control with push button or remote control, double technology with Bluetooth® wireless technology 5.0 standard for the realization of View Wireless mesh system and Zigbee 3.0 standard, function for measuringthe instant power and load cut-off threshold, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, white
- Compatible with SmartThings hub
产品状态
3 - Active
您可能也感兴趣
单, 说明书, 文档
- Light multilanguage instructions sheet (987 kb)
- Foglio istruzioni Full (551 kb)
- Feuille d’instructions Full (549 kb)
- Hoja de instrucciones Full (547 kb)
- Full instructions sheet (545 kb)
- Φυλλάδιο οδηγιών Full (720 kb)
- Anweisungsblatt Full (547 kb)
- ورقة الإرشادات Full (611 kb)
- Manuale app View Wireless (19181 kb)
- Manual View Wireless app (40958 kb)
- Manual app View Wireless (40735 kb)
- Installationsanleitung View Wireless (40757 kb)
- Manuel appli View Wireless (40963 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (41171 kb)
图纸
Class group
Installation bus systems
Installation bus systems
Class
Switch actuator for bus system
Switch actuator for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
Yes
Yes
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
None
None
Radio frequency bidirectional
No
No
Mounting method
Flush-mounted
Flush-mounted
Width in number of modular spacings
1
1
Local operation/hand operation
No
No
With LED indication
Yes
Yes
Number of digital inputs
0
0
Suitable for C-load
Yes
Yes
Max. number of switching contacts
1
1
Max. switching current
16 A
16 A
Rated current
16 A
16 A
Rated operating voltage
100,00 - 240,00 V
100,00 - 240,00 V
Different phases connectable
No
No
With bus connection
Yes
Yes
Bus module detachable
No
No
Modular expandability
No
No
Degree of protection (IP)
IP40
IP40
37. Marking - Morocco
40. Bluetooth technology
42. Zigbee certified
最小订单数量: 1 NR
条形码
8007352690110
1 NR
6x4.5x5.4 [cm]
56.96 [g]
8007352744882
72 NR
37.5x30x13.5 [cm]
4,504.75 [g]
