16A IoT connected actuator canvas - 30803.C

Pdf

Vimar - 30803.C - 16A IoT connected actuator canvas

30803.C
Wiring devices / View Wireless wiring devices / LINEA / Devices

16A IoT connected actuator canvas
VIEW Wireless electronic control device with NO 16 A 100-240 V~ relay output, local control with push button or remote control, double IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system and on Zigbee 3.0 standard, function for measuring the instant power and energy consumed and load cut-off threshold, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, canvas

Compatible with SmartThings hub

产品状态
3 - Active

您可能也感兴趣

30807.C - IoT connected Gateway 2M canvas

单, 说明书, 文档

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Switch actuator for bus system

Bus system KNX
No

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
Yes

Bus system LON
No

Bus system Powernet
No

Other bus systems
None

Radio frequent bidirectional
No

Mounting method
Flush-mounted

Width in number of modular spacings
2

Local operation/hand operation
No

With LED indication
Yes

Number of digital inputs
0

Suitable for C-load
Yes

Max. number of switching contacts
1

Max. switching current
16 A

Rated current
16 A

Rated operating voltage
100,00 - 240,00 V

Different phases connectable
No

With bus connection
Yes

Bus module detachable
No

Modular expandability
No

Degree of protection (IP)
IP40

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352690134

1 NR

6x5.4x5.2 [cm]

56.96 [g]

8007352690141

60 NR

37.5x30x13.5 [cm]

3,754 [g]

8007352744899

72 NR

37.5x30x13.5 [cm]

4,504.75 [g]

分享

Codice QR scheda articolo

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
