IoT connected dimmer mechanism代码 30805
- 30805
- Wiring devices / View Wireless wiring devices / LINEA / Devices
- IoT connected dimmer mechanism
- VIEW Wireless electronic dimmer mechanism for 20-200 W incandescent lamps, 2-200 W LED lamps, 20-200 W electronic transformers, double IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system and on Zigbee 3.0 standard, 1 input for external push button for dimmer control or to recall a scenario, RGB LED visible in darkness with brightness control, 220-240 V 50/60 Hz power supply, to be completed with Linea 1-module interchangeable buttons
- Compatible with both LE and TE dimmable lamps
- Also configurable as a 1-way switch pending the installation of a dimmable lamp
- Bluetooth mode compatible with Amazon Alexa, Google Assistant, Apple Homekit and IFTTT voice assistants, via the dedicated Vimar gateway
- Zigbee mode compatible with the Amazon Alexa voice assistant, via Amazon Zigbee hub
- 产品状态
- 3 - Active
您可能也感兴趣
单, 说明书, 文档
- Light multilanguage instructions sheet (1328 kb)
- Foglio istruzioni multilingua Full (676 kb)
- Feuille d’instructions multilangues Full (676 kb)
- Hoja de instrucciones multilingüe Full (673 kb)
- Full Multilanguage instructions sheet (669 kb)
- Πολυγλωσσικό φύλλο οδηγιών Full (832 kb)
- Mehrsprachig-Gebrauchsinformation Full (675 kb)
- ورقة الإرشادات Full (749 kb)
- Manuale app View Wireless (19693 kb)
- Manuel appli View Wireless (43543 kb)
- Manual app View Wireless (43542 kb)
- Manual View Wireless app (42589 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (43825 kb)
- Installationsanleitung View Wireless (43598 kb)
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Installation switch
Installation switch
Wiring system
Other
Other
Operating method
Rocker/button
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Number of modules (module system)
1
1
Push button switch
Yes
Yes
Number of rockers
1
1
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
With mounting plate
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Anti-bacterial treatment
No
No
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Black
Black
RAL-number (similar)
7024
7024
Label space/information surface
No
No
Lighting
Yes
Yes
Function lighting
Control and orientation
Control and orientation
Type of lighting
LED not exchangeable
LED not exchangeable
Suitable for degree of protection (IP)
IP40
IP40
Impact strength
Other
Other
Nominal voltage
240 V
240 V
Monitoring contact
No
No
Connection type
Screwed terminal
Screwed terminal
Heating switch
No
No
Washing machine switch
No
No
Device width
22,20 mm
22,20 mm
Device height
49,50 mm
49,50 mm
Device depth
42,70 mm
42,70 mm
Built-in depth
39,00 mm
39,00 mm
Compatible with Apple HomeKit
Yes
Yes
Compatible with Google Assistant
Yes
Yes
Compatible with Amazon Alexa
Yes
Yes
IFTTT support available
Yes
Yes
37. Marking - Morocco
40. Bluetooth technology
42. Zigbee certified
47. Works with SmartThings
最小订单数量: 1 NR
条形码
8007352707184
1 NR
5.1x3.5x5.5 [cm]
41.55 [g]
8007352744875
60 NR
27x23x12.5 [cm]
2,683 [g]
