30805.120
Wiring devices / View Wireless wiring devices / LINEA / Devices
IoT connected dimmer mechanism 120V
VIEW Wireless electronic dimmer mechanism for 20-200 W incandescent lamps, 2-200 W LED lamps, 20-200 W electronic transformers, double IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system and on Zigbee 3.0 standard, 1 input for external push button for dimmer control or to recall a scenario, RGB LED visible in darkness with brightness control, 120 V 50/60 Hz power supply, to be completed with Linea 1-module interchangeable buttons
产品状态
3 - Active
单, 说明书, 文档
- Light multilanguage instructions sheet (1141 kb)
- Foglio istruzioni multilingua Full (670 kb)
- Feuille d’instructions multilangues Full (671 kb)
- Hoja de instrucciones multilingüe Full (668 kb)
- Full Multilanguage instructions sheet (664 kb)
- Πολυγλωσσικό φύλλο οδηγιών Full (822 kb)
- Mehrsprachig-Gebrauchsinformation Full (668 kb)
- ورقة الإرشادات Full (737 kb)
- Manuale app View Wireless (19693 kb)
- Manuel appli View Wireless (43543 kb)
- Manual app View Wireless (43542 kb)
- Manual View Wireless app (42589 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (43825 kb)
- Installationsanleitung View Wireless (43598 kb)
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Installation switch
Installation switch
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Anthracite
Anthracite
RAL-number (similar)
7021
7021
Device width
22,20 mm
22,20 mm
Device height
49,50 mm
49,50 mm
Device depth
42,70 mm
42,70 mm
Built-in depth
39,00 mm
39,00 mm
最小订单数量: 1 NR
条形码

8007352713840
1 NR
5.1x3.5x5.5 [cm]
51.4 [g]

8007352744820
60 NR
27x23x12.5 [cm]
3,280 [g]
