30810.C
Wiring devices / View Wireless wiring devices / LINEA / Devices
IoT dial thermostat 2M canvas
Dial thermostat with relay output 5(2) A 240 V~, IoT technology on Bluetooth technology 5.0 standard for the creation of VIEW Wireless mesh system, 1 input for external temperature sensor, 100-240 V~ 50/60 Hz power supply, heating and air conditioning in ON/OFF and PID mode, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, white LED backlighting with brightness control, canvas - 2 modules
- It is compatible with voice assistants Alexa and Google Home through Skill and Action VIEW Product
- Maximum simplicity thanks to the large knob
- Configuration via “VIEW Wireless” App for Bluetooth technology system
- Hotkeys are designed for quick interaction
产品状态
3 - Active
您可能也感兴趣
单, 说明书, 文档
- Light multilanguage instructions sheet (1051 kb)
- Foglio istruzioni multilingua Full (697 kb)
- Feuille d’instructions multilangues Full (701 kb)
- Hoja de instrucciones multilingüe Full (698 kb)
- Full multilanguage instructions sheet (693 kb)
- Πολυγλωσσικό φύλλο οδηγιών Full (861 kb)
- Mehrsprachig-Gebrauchsinformation Full (700 kb)
- ورقة الإرشادات Full (830 kb)
- Manuale app View Wireless (19181 kb)
- Manual View Wireless app (40958 kb)
- Manual app View Wireless (40735 kb)
- Installationsanleitung View Wireless (40757 kb)
- Manuel appli View Wireless (40963 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (41171 kb)
图纸
Class group
Stats, switches and controllers
Stats, switches and controllers
Class
Room thermostat
Room thermostat
Model
Other
Other
Type of power supply
230 V AC
230 V AC
Connection
3-/4-wire
3-/4-wire
With receiver
No
No
Measuring range
0 - 40 °C
0 - 40 °C
External sensor
Yes
Yes
Thermal feedback
Parallel
Parallel
Control characteristic
PID
PID
Suitable for heating
Yes
Yes
Number of heater outputs
1
1
Suitable for cooling
Yes
Yes
Number of cooler outputs
1
1
Differential value
0,10 - 1,00 k
0,10 - 1,00 k
Adjustable differential
Yes
Yes
Temperature readable
Yes
Yes
With sound indicator
No
No
Sensor/feeler type
Resistance sensor
Resistance sensor
Mounting method
Flush-mounted
Flush-mounted
Number of modules (module system)
2
2
With display
Yes
Yes
Operation
Turn
Turn
With tap water circuit
No
No
Contact type
Normally open contact (NO)
Normally open contact (NO)
Max. contact voltage
230 V
230 V
Max. contact load
5 A
5 A
Degree of protection (IP)
IP20
IP20
Degree of protection (NEMA)
Other
Other
Explosion-proof
No
No
Colour
Beige
Beige
RAL-number
7032
7032
Height
52,80 mm
52,80 mm
Width
44,80 mm
44,80 mm
Depth
41,70 mm
41,70 mm
Diameter
0 mm
0 mm
Class of the temperature control
IV
IV
Compatible with Apple HomeKit
Yes
Yes
Compatible with Google Assistant
Yes
Yes
Compatible with Amazon Alexa
Yes
Yes
IFTTT support available
Yes
Yes
37. Marking - Morocco
40. Bluetooth technology
42. Zigbee certified
最小订单数量: 1 NR
条形码
8007352691148
1 NR
6x5.4x5.2 [cm]
71.2 [g]
8007352691155
10 NR
28.1x13.1x6 [cm]
800.8 [g]
8007352691162
120 NR
38.5x29x30 [cm]
10,049 [g]
