IoT dial thermostat 2M black - 30810.G

Pdf

Vimar - 30810.G - IoT dial thermostat 2M black

30810.G
Wiring devices / View Wireless wiring devices / LINEA / Devices

IoT dial thermostat 2M black
Dial thermostat with relay output 5(2) A 240 V~, IoT technology on Bluetooth technology 5.0 standard for the creation of VIEW Wireless mesh system, 1 input for external temperature sensor, 100-240 V~ 50/60 Hz power supply, heating and air conditioning in ON/OFF and PID mode, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, white LED backlighting with brightness control, black - 2 modules.

It is compatible with voice assistants Alexa and Google Home through Skill and Action VIEW Product
Maximum simplicity thanks to the large knob
Configuration via “VIEW Wireless” App for Bluetooth technology system
Hotkeys are designed for quick interaction

产品状态
3 - Active

您可能也感兴趣

30807.G - IoT connected Gateway 2M black

单, 说明书, 文档

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Stats, switches and controllers

Class
Room thermostat

Model
Other

Type of power supply
230 V AC

Connection
3-/4-wire

With receiver
No

Measuring range
0 - 40 °C

External sensor
Yes

Thermal feedback
Parallel

Control characteristic
PID

Suitable for heating
Yes

Number of heater outputs
1

Suitable for cooling
Yes

Number of cooler outputs
1

Differential value
0,10 - 1,00 k

Adjustable differential
Yes

Temperature readable
Yes

With sound indicator
No

Sensor/feeler type
Resistance sensor

Mounting method
Flush-mounted

Number of modules (module system)
2

With display
Yes

Operation
Turn

With tap water circuit
No

Contact type
Normally open contact (NO)

Max. contact voltage
230 V

Max. contact load
5 A

Degree of protection (IP)
IP20

Degree of protection (NEMA)
Other

Explosion-proof
No

Colour
Black

RAL-number
7021

Height
52,80 mm

Width
44,80 mm

Depth
41,70 mm

Diameter
0 mm

Class of the temperature control
IV

Compatible with Apple HomeKit
Yes

Compatible with Google Assistant
Yes

Compatible with Amazon Alexa
Yes

IFTTT support available
Yes

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352689367

1 NR

6x5.4x5.2 [cm]

71 [g]

8007352689374

10 NR

28.1x13.1x6 [cm]

799.8 [g]

8007352689381

120 NR

38.5x29x30 [cm]

10,040 [g]
