Interphone supply unit 2F+ 100-240V 0,6A - 40100

Pdf
Vimar - 40100 - Interphone supply unit 2F+ 100-240V 0,6A
Vimar - 40100 - Interphone supply unit 2F+ 100-240V 0,6A

40100
ELVOX Door entry system / 2F/2F+ video door entry system / Shared A/V components / System components

Interphone supply unit 2F+ 100-240V 0,6A
Supply unit for Due Fili Plus 1- and 2-family door entry system kits, with 28 Vdc 0,6 A output, supply voltage 110-240 V~ 50/60 Hz, on DIN (60715 TH35) rail installation, occupies 6 17.5 mm modules

产品状态
3 - Active

Class group
Communication technique
Class
Power supply door communication
Application
Other
Input voltage
240 V
Type of current
DC
Output voltage
28,00 V
Short-circuit-proof
Yes
Degree of protection (IP)
IP30
Height
106,00 mm
Width
107,80 mm
Depth
63,00 mm
Installation technique
Bus system
Integrated door opening circuit
No
Control function
No
Evaluation function
No
Service indication
No
Mounting method
Other
Programming lock
No
With contact
No

00. CE Marking - EU

01. IMQ - Italy

32. FCC - USA

43. UKCA mark - Great Britain

92. RoHS UAE

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352654228
1 NR
11.9x11.5x6.9 [cm]
311.81 [g]
Barcode Qty 26 NR
8007352654242
26 NR
38x34x24 [cm]
8,607.06 [g]
