4621.028B
Safety / ELVOX CCTV / IP / Cameras
Bullet IR IP 2Mpx cam - 2,8mm H.265
Day & Night colour IP Bullet camera, CMOS 1/2.8” sensor, 2 Mpx resolution (1920x1080), 2.8mm fixed focus lens, mechanical IR filter, H.265 Dual Stream, PoE or 12 VDC power supply, SD CARD slot, IR 20-30 m, AV, WDR, ROI, 3DDNR, HLC, BLC, Mask, Motion, Smart IR, RTSP functions, ONVIF protocol, protection degree IP67. Dimensions: 75x75x168 mm. Weight 435 g
产品状态
2 - Will be discontinued
您可能也感兴趣
单, 说明书, 文档
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Camera for surveillance system
Camera for surveillance system
Model
Standard (Fixed)
Standard (Fixed)
Construction type
Bullet shape
Bullet shape
Thermal camera
No
No
Number of pixels (Megapixel)
2
2
With lens
Yes
Yes
Modular (lens and camera separated)
No
No
Shutter control
DC
DC
Lens connection
Other
Other
Motor zoom
No
No
Suitable for wall mounting
Yes
Yes
Suitable for ceiling mounting
Yes
Yes
Suitable for corner mounting
No
No
Suitable for surface mounting
Yes
Yes
Flush-mounted installation/built-in installation
No
No
Suitable for outdoor use
Yes
Yes
Communication medium wired
Yes
Yes
Communication medium wireless
No
No
Type of interface
Wi-Fi
Wi-Fi
Protocol
TCP/IP
TCP/IP
Power over Ethernet (PoE)
802.3af (PoE)
802.3af (PoE)
Picture system
PAL
PAL
Frame rate
25
25
Property picture system
Colour
Colour
With infrared lighting
Yes
Yes
Max. infrared reach
30 m
30 m
With white light
No
No
Max. white light reach
0 m
0 m
Supports H.264 codec
Yes
Yes
Supports H.265 codec
Yes
Yes
Supports Motion JPEG codec
Yes
Yes
Supports MPEG-4 codec
No
No
With video motion detector
Yes
Yes
With integrated AI analysis
Yes
Yes
With slot for memory card
Yes
Yes
With memory card
No
No
Memory capacity
256
256
Number of digital inputs
1
1
Number of digital outputs
1
1
With integrated audio analysis
No
No
HDMI-connection
No
No
Mini HDMI-connection
No
No
VGA-connection (D-Sub 15-pole)
No
No
DVI-connection
No
No
BNC-connection
No
No
DisplayPort-connection
No
No
Mini DisplayPort
No
No
S-Video-connection
No
No
USB-C-connection
No
No
Vandal proof
No
No
Impact strength
IK00
IK00
Degree of protection (IP)
IP66
IP66
With microphone
Yes
Yes
With loudspeaker
No
No
Supply voltage
12,00 - 12,01 V
12,00 - 12,01 V
Voltage type
DC
DC
Colour
White
White
Diameter
7.500,00 mm
7.500,00 mm
Height
75,00 mm
75,00 mm
Width
7.500,00 mm
7.500,00 mm
Depth
168,00 mm
168,00 mm
Compatible with Apple HomeKit
No
No
Compatible with Google Assistant
No
No
Compatible with Amazon Alexa
No
No
IFTTT support available
No
No
最小订单数量: 1 NR
条形码
8007352700727
1 NR
23x10.5x11 [cm]
557 [g]
