IR AHD Dome cam - 1080p 2,8mm OSD - 4652.028B

Pdf
Vimar - 4652.028B - IR AHD Dome cam - 1080p 2,8mm OSD
Vimar - 4652.028B - IR AHD Dome cam - 1080p 2,8mm OSD
4652.028B

ELVOX CCTV / AHD / Dome cameras

IR AHD Dome cam - 1080p 2,8mm OSD
Day&Night AHD Dome camera, Full-HD 1080p resolution, 2 Mpx 1/2.9” sensor, mechanical IR filter, 2.8mm fixed lens, CsC function, 0 lux IR in ON sensitivity, protection degree IP66, IR illuminator with range up to 15m, Smart-IR, AHD-CVBS-TVI-CVI switching. 12 V DC 350 mA power supply, complete with bracket and protected cable outlet. Dimensions: 80(A) 94(Ø) mm. Weight 320 g.

产品状态
2 - Will be discontinued

Class group
Alarm installations, emergency call and signalling
Class
Camera for monitoring system
Mounting method
Wall/ceiling
Scope of application
Universal
Picture system
PAL
Property picture system
Colour
Colour
White
Wireless
No
With IR lamp
Yes
Vandal proof
No
Supply voltage
12,00 - 12,01 v
Voltage type
DC
Diameter
9.400 mm
Height
70,00 mm
Width
9.400 mm
Depth
70,00 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8013406311542
1 NR
12.2x12.5x9 [cm]
397 [g]
