Dome AHD cam 5Mpx 3,6mm - 4652.036E

Pdf
4652.036E

ELVOX CCTV / AHD / Dome cameras

Dome AHD cam 5Mpx 3,6mm
Day & Night AHD Dome camera, 5 Mpx resolution, 1/2.8in sensor, mechanical IR filter, 3.6mm fixed lens, CsC function, 0 lux IR in ON sensitivity, protection degree IP66, IR illuminator with range up to 15m, Smart-IR, AHD-CVBS switching, automatic functions: BLC, 2-3DNR, AGC, WHITEBAL,D-WDR. 12 V DC 400 mA power supply, complete with bracket and protected cable outlet. Dimensions: 80(A) 94(Ø) mm. Weight 320 g

产品状态
4 - Active

Class group
Alarm installations, emergency call and signalling
Class
Camera for monitoring system
Mounting method
Wall/ceiling
Scope of application
Universal
Picture system
PAL
Property picture system
Colour
Colour
White
Wireless
No
With IR lamp
Yes
Vandal proof
No
Supply voltage
12,00 - 12,01 v
Voltage type
DC
Diameter
94 mm
Height
70,00 mm

00. CE Marking - EU

37. Marking - Morocco

92. RoHS UAE

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8013406311603
1 NR
12x12x9 [cm]
392.5 [g]
