46534.037BP
Safety / ELVOX CCTV / AHD / Cameras
Pinhole AHD cam 1080p 3,7mm
Special pinhole camera, Full-HD 1080p resolution, 1/2.9in sensor, electronic IR filter, fixed 3.7 mm Pinhole lens, 0.001 lux sensitivity. Functions: 2-3DNR, D-WDR, BLC, HSBLC, Defog, CoC. 12 V DC 95 mA power supply. Dimensions 45x38.5x24mm. Weight 74 g.
产品状态
2 - Will be discontinued
单, 说明书, 文档
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Camera for surveillance system
Camera for surveillance system
Model
Standard (Fixed)
Standard (Fixed)
Construction type
Pin hole shape
Pin hole shape
Thermal camera
No
No
Number of pixels (Megapixel)
2
2
With lens
Yes
Yes
Modular (lens and camera separated)
No
No
Focal size
3,70 - 3,71 mm
3,70 - 3,71 mm
Shutter control
DC
DC
Lens connection
Other
Other
Motor zoom
No
No
Suitable for wall mounting
Yes
Yes
Suitable for ceiling mounting
Yes
Yes
Suitable for corner mounting
No
No
Suitable for surface mounting
Yes
Yes
Flush-mounted installation/built-in installation
No
No
Suitable for outdoor use
No
No
Communication medium wired
Yes
Yes
Communication medium wireless
No
No
Type of interface
Other
Other
Protocol
Other
Other
Power over Ethernet (PoE)
None
None
Picture system
PAL
PAL
Frame rate
25
25
Property picture system
Colour
Colour
With infrared lighting
Yes
Yes
Max. infrared reach
0 m
0 m
With white light
No
No
Max. white light reach
0 m
0 m
Supports H.264 codec
No
No
Supports H.265 codec
No
No
Supports Motion JPEG codec
Yes
Yes
Supports MPEG-4 codec
No
No
With video motion detector
No
No
With integrated AI analysis
No
No
With slot for memory card
No
No
With memory card
No
No
Memory capacity
0
0
Number of digital inputs
0
0
Number of digital outputs
0
0
Number of audio inputs
0
0
Number of audio outputs
0
0
With integrated audio analysis
No
No
HDMI-connection
No
No
Mini HDMI-connection
No
No
VGA-connection (D-Sub 15-pole)
No
No
DVI-connection
No
No
BNC-connection
Yes
Yes
DisplayPort-connection
No
No
Mini DisplayPort
No
No
S-Video-connection
No
No
USB-C-connection
No
No
Vandal proof
No
No
Impact strength
Other
Other
Degree of protection (IP)
Other
Other
Horizontal field of view
67,00 - 67,10
67,00 - 67,10
With microphone
No
No
With loudspeaker
No
No
Power consumption
1,14 W
1,14 W
Supply voltage
0,10 - 12,01 V
0,10 - 12,01 V
Voltage type
DC
DC
Colour
Black
Black
Diameter
0,00 mm
0,00 mm
Height
45,00 mm
45,00 mm
Width
28,50 mm
28,50 mm
Depth
24,00 mm
24,00 mm
Compatible with Apple HomeKit
No
No
Compatible with Google Assistant
No
No
Compatible with Amazon Alexa
No
No
IFTTT support available
No
No
最小订单数量: 1 NR
条形码
8013406309570
1 NR
12.5x12.5x9.4 [cm]
143 [g]
