16-channel AHD DVR 1080p - 46540.H16

Pdf
Vimar - 46540.H16 - 16-channel AHD DVR 1080p
Vimar - 46540.H16 - 16-channel AHD DVR 1080p
46540.H16

ELVOX CCTV / AHD / DVR

16-channel AHD DVR 1080p
Hybrid DVR with 16+4 channels AHD/IP/CVBS compatible with 4 additional IP video cameras, professional HDD 1 TB with free slot for max 3TB expansion, Pentaplex, H.264, CsC function, supports AHD up to 1080P (Full-HD @ 25 fps) and IP up to 3 Mpx (3Mpx @ 12fps, Full-HD @ 25 fps), 1 in/1 out audio outputs, 4 in/1 out alarm management outputs, RS485 port, 2 USB, BNC outputs (only CVBS), VGA, HDMI, up to Full HD, RJ45 Ethernet, privacy masking, motion detection, integrated web interface, CVM software, smart-phone and QRCODE control. 12 Vdc, 2 A Power supply included. Dimensions 380x286x52 mm.

产品状态
2 - Will be discontinued

Class group
Alarm installations, emergency call and signalling
Class
Matrix memory for video surveillance system
Recording type
Analogue
Max. number of video inputs
16
With video motion detector
Yes
Redundant power supply
No
Power over Ethernet (PoE)
None
Operating system
Linux
Number of pre-licensed cameras
16
Number of hard disc bays
2
Number of preinstalled hard discs
0
Memory capacity per hard disc
1
RAID 0 capable
No
RAID 1 capable
No
RAID 5 capable
No
Hot-swappable hard disk capability
No
Width
380 mm
Height
52 mm
Depth
268 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8013406274939
1 NR
51x34.5x11.5 [cm]
3,150 [g]
