46558.2812E
Safety / ELVOX CCTV / AHD / Kits
8-channel AHD kit -2xBullet VF 5Mpx cam
AHD CCTV kit consisting of: Hybrid DVR with 8+4 AHD/IP channels, compatible with 4 additional IP cameras, professional 1 TB HDD, H.265 compression, CsC, supports AHD and IP up to 5Mpx (code 46XVR.ES08), 2 bullet 5Mpx AHD cameras with 2.8-12 mm varifocal lens, D&N with mechanical IR filter (code 4651.2812ES), 2 x 12 VDC - 1A plug-in power supply units (code 46902.010), 1 “Area under video surveillance” sign (code 46927.001)
产品状态
3 - Active
套件元件
您可能也感兴趣
单, 说明书, 文档
- Integrazione Elvox TVCC nei touch screen (779 kb)
- Elvox CCTV integration in touch screens (740 kb)
- Interfaccia grafica videoregistratori (25361 kb)
- Videorecorder graphical user interface (25293 kb)
- Configurazione analisi video per DVR/NVR (13835 kb)
- DVR/NVR video analysis configuration (13802 kb)
产品配套软件
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Video surveillance system
Video surveillance system
Model camera
Standard (Fixed)
Standard (Fixed)
Construction type
Bullet shape
Bullet shape
Suitable for wall mounting
Yes
Yes
Suitable for ceiling mounting
Yes
Yes
Suitable for corner mounting
No
No
Suitable for surface mounting
No
No
Flush-mounted installation/built-in installation
No
No
Suitable for outdoor use
Yes
Yes
Number of cameras
2
2
Thermal camera
No
No
Number of included cameras
2
2
With video motion detector
Yes
Yes
With infrared lighting
Yes
Yes
Number of pixels (Megapixel)
5
5
Picture system
PAL
PAL
Property picture system
Colour
Colour
Degree of protection (IP) camera
IP66
IP66
Integrated power-supply for cameras
Yes
Yes
Transmission technique
Other
Other
Wired camera connection
Yes
Yes
Wireless camera connection
No
No
Type of interface
Other
Other
Type of connector
Other
Other
Type of storage medium
Hard disc
Hard disc
Cloud-based storage
No
No
Memory capacity included storage medium
1000
1000
Number of RJ45 connections
1
1
Internal memory capacity camera
256
256
Max. number of video inputs
8
8
With monitor
No
No
Number of HDMI connections
1
1
Number of Mini HDMI connections
0
0
Number of DVI sockets
0
0
Number of inputs DisplayPort (DP)
0
0
Number of inputs Mini DisplayPort (mDP)
0
0
Number of D-Sub connections 15-pole
0
0
Number of BNC connections
8
8
Compatible with Apple HomeKit
No
No
Compatible with Google Assistant
No
No
Compatible with Amazon Alexa
No
No
IFTTT support available
No
No
最小订单数量: 1 NR
条形码
8007352722392
1 NR
58x54.5x15 [cm]
3,020 [g]
