LED monitor 22in VGA/HDMI inputs代码 46910.H22B

Name: LED monitor 22in VGA/HDMI inputs
Brand: Vimar
Availability: InStock

以 PDF 格式下载PDF

46910.H22B: Safety / ELVOX CCTV / Universal / Monitor
LED monitor 22in VGA/HDMI inputs: 22” LCD monitor, LED backlighting, 16:9 video format, Full HD resolution 1920x1080 pixels, VGA and HDMI video inputs, audio input with two 3 W speakers, 16.7 M colours, brightness 250 cd/m², contrast 1000:1, 5 ms response time, VESA fixing, 12 VDC 15 W power supply (power supply unit included). Dimensions: 490x370x137 mm
产品状态: 3 - Active

单, 说明书, 文档

Multilanguage instructions sheet (939 kb)

Class group
Telecommunication equipment/office devices

Class
Monitor

Type of display
LCD

Resolution
Full HD

Housing colour
Black

With display backlight
Yes

Colour display
Yes

Number of colours of the display
16,7

Visible diagonal screen size
55,88 cm

Visible diagonal screen size (inch)
22

Number of pixels, horizontal
1920

Number of pixels, vertical
1080

Image format
16:9

With on-screen keyboard
No

With touch screen
No

Mouse-cursor control integrated
No

Supply voltage AC 50 Hz
0 V

Supply voltage AC 60 Hz
0 V

Supply voltage DC
12 V

Voltage type (supply voltage)
DC

Number of HDMI connections
1

Number of Mini HDMI connections
0

Number of DVI sockets
0

Number of inputs DisplayPort (DP)
0

Number of inputs Mini DisplayPort (mDP)
0

Number of BNC connections
0

VGA-connection (D-Sub 15-pole)
No

Number of ports USB-A
0

Number of ports USB-C
0

With HW-interface PS2
No

Freestanding
Yes

Suitable for rail mounting
No

Wall mounting/direct mounting
Yes

Front built-in possible
Yes

Rack-assembly possible
No

Mounting Interface Standard (MIS) according to VESA
200x200

Suitable for safety functions
Yes

Degree of protection (IP)
IP20

Width
490 mm

Height
370 mm

Depth
42 mm

Angle of inclination
0 - 170

Height adjusting range
0 mm

Compatible with Apple HomeKit
No

Compatible with Google Assistant
No

Compatible with Amazon Alexa
No

IFTTT support available
No

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352739031

1 NR

56x42.5x11 [cm]

3,600 [g]

合法
