46NVR.32N
Safety / ELVOX CCTV / IP / NVR
NVR 32Ch 12Mpx H.265s HDD 2TB NDAA
32-channel NVR, H.265s compression, Pentaplex function, 32-channel 12 Mpx Real Time recording resolution, Professional 2 TB HDD, SATA x2, max 10 TB for HDD, 1IN/1OUT audio connections, 8IN/4OUT alarms management, 3 USB, VGA, HDMI with resolution up to 4K, remote control and viewing, QRCODE, privacy mask, motion detection, ONVIF protocol, NDAA compliant, CVM software. Dimensions: 380x269x52 mm
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Image storage for video surveillance system
Image storage for video surveillance system
Recording type
Digital
Digital
Device construction
482.6 mm (19 inch) mounting rack
482.6 mm (19 inch) mounting rack
Number of hard disc bays
2
2
Number of preinstalled hard discs
1
1
Memory capacity per hard disc
2
2
Max. number of video inputs
32
32
Max. number of control inputs
0
0
Number of HDMI connections
2
2
Number of Mini HDMI connections
0
0
Number of DVI sockets
0
0
Number of RJ45 connections
2
2
Number of inputs DisplayPort (DP)
0
0
Number of inputs Mini DisplayPort (mDP)
0
0
Number of D-Sub connections 15-pole
0
0
Number of BNC connections
0
0
Number of ports USB-A
0
0
Number of ports USB-C
2
2
Supports H.264 codec
Yes
Yes
Supports H.265 codec
Yes
Yes
Supports Motion JPEG codec
Yes
Yes
Supports MPEG-4 codec
No
No
With video motion detector
Yes
Yes
With integrated AI analysis
Yes
Yes
With integrated audio analysis
No
No
Number of ports 1000 Mbps Mini GBIC
0
0
Number of combination-ports RJ45/Mini GBIC
2
2
Number of ports PoE
0
0
Max. PoE power
0 W
0 W
Power over Ethernet (PoE)
None
None
With DVD
No
No
Redundant power supply
No
No
Power consumption
25 W
25 W
Max. recording resolution
8
8
Max. data transmission rate
1000
1000
Max. transmission rate input
320
320
Max. transmission rate output
320
320
Operating system
Linux
Linux
Number of pre-licensed cameras
32
32
RAID 0 capable
No
No
RAID 1 capable
No
No
RAID 5 capable
No
No
RAID 6 capable
No
No
RAID 10 capable
No
No
Hot-swappable hard disk capability
No
No
Width
268 mm
268 mm
Height
45 mm
45 mm
Depth
380 mm
380 mm
00. CE Marking - EU
37. Marking - Morocco
最小订单数量: 1 NR
条形码
8007352763586
1 NR
51.2x34.8x11 [cm]
3,160 [g]
