46XVR.FS04
Safety / ELVOX CCTV / AHD / DVR
4-channel AHD 4K Lite HDD XVR - 1TB
Hybrid DVR with 4 channels AHD/CVBS compatible with 2 additional IP cameras, professional 1 TB HDD, H.265 compression, CsC function, supports AHD up to 8 Mpx (8Mpx Lite@ 12fps, 5Mpx @12fps, 5Mpx Lite@20fps, 4/3Mpx @12fps, 4Mpx Lite/1080p/720/WD1@25 fps) and IP up to 8 Mpx (20 fps), 1 in/1 out audio, RS485 port, 2 USB, BNC output (CVBS or SPOT), VGA up to 1080p and HDMI up to 4K, RJ45 Ethernet, web interface, CVM, remote control and QRCODE. 12 VDC power supply unit included. Dim. 255x222x42 mm
产品状态
2 - Will be discontinued
其他可选产品
您可能也感兴趣
单, 说明书, 文档
- Integrazione Elvox TVCC nei touch screen (779 kb)
- Elvox CCTV integration in touch screens (740 kb)
- Multilanguage instructions sheet (1500 kb)
- Interfaccia grafica videoregistratori (25361 kb)
- Videorecorder graphical user interface (25293 kb)
- Configurazione analisi video per DVR/NVR (13835 kb)
- DVR/NVR video analysis configuration (13802 kb)
产品配套软件
图纸
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Image storage for video surveillance system
Image storage for video surveillance system
Recording type
Digital
Digital
Device construction
Desktop
Desktop
Number of hard disc bays
1
1
Number of preinstalled hard discs
1
1
Memory capacity per hard disc
1
1
Max. number of video inputs
4
4
Max. number of control inputs
0
0
Number of HDMI connections
1
1
Number of Mini HDMI connections
0
0
Number of DVI sockets
0
0
Number of RJ45 connections
1
1
Number of inputs DisplayPort (DP)
0
0
Number of inputs Mini DisplayPort (mDP)
0
0
Number of D-Sub connections 15-pole
0
0
Number of BNC connections
4
4
Number of ports USB-A
0
0
Number of ports USB-C
2
2
Supports H.264 codec
Yes
Yes
Supports H.265 codec
Yes
Yes
Supports Motion JPEG codec
Yes
Yes
Supports MPEG-4 codec
No
No
With video motion detector
No
No
With integrated AI analysis
Yes
Yes
With integrated audio analysis
No
No
Number of ports 1000 Mbps Mini GBIC
0
0
Number of combination-ports RJ45/Mini GBIC
0
0
Number of ports PoE
0
0
Max. PoE power
0 W
0 W
Power over Ethernet (PoE)
None
None
With DVD
No
No
Redundant power supply
No
No
Power consumption
12 W
12 W
Max. recording resolution
8
8
Max. data transmission rate
100
100
Operating system
Other
Other
Number of pre-licensed cameras
4
4
RAID 0 capable
No
No
RAID 1 capable
No
No
RAID 5 capable
No
No
RAID 6 capable
No
No
RAID 10 capable
No
No
Hot-swappable hard disk capability
No
No
Width
255 mm
255 mm
Height
264 mm
264 mm
Depth
42 mm
42 mm
最小订单数量: 1 NR
条形码
8007352717558
1 NR
36.5x29.5x9 [cm]
1,470.5 [g]
