46XVR.FS16
Safety / ELVOX CCTV / AHD / DVR
16-channel AHD 4K Lite HDD XVR - 2TB
Hybrid DVR with 16 channels AHD/CVBS compatible with 8 additional IP cameras, professional 2 TB HDD, H.265 compression, CsC function, supports AHD up to 8 Mpx (8Mpx @8fps, 8Mpx Lite@ 12fps, 5Mpx @12fps, 5Mpx Lite@20fps, 4/3Mpx @12fps, 4Mpx Lite/1080p/720/WD1@25 fps) and IP up to 8 Mpx (25 fps), 1 in/1 out audio, RS485 port, 2 USB, BNC output (CVBS or SPOT), VGA up to 1080p and HDMI up to 4K, RJ45 Ethernet, web interface, CVM, remote control and QRCODE. 12 VDC power supply unit included. Dim. 380x268x45 mm
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Image storage for video surveillance system
Image storage for video surveillance system
Recording type
Digital
Digital
Device construction
Desktop
Desktop
Number of hard disc bays
2
2
Number of preinstalled hard discs
1
1
Memory capacity per hard disc
10
10
Max. number of video inputs
16
16
Max. number of control inputs
16
16
Number of HDMI connections
1
1
Number of Mini HDMI connections
0
0
Number of DVI sockets
0
0
Number of RJ45 connections
1
1
Number of inputs DisplayPort (DP)
0
0
Number of inputs Mini DisplayPort (mDP)
0
0
Number of D-Sub connections 15-pole
0
0
Number of BNC connections
16
16
Number of ports USB-A
0
0
Number of ports USB-C
2
2
Supports H.264 codec
Yes
Yes
Supports H.265 codec
Yes
Yes
Supports Motion JPEG codec
Yes
Yes
Supports MPEG-4 codec
No
No
With video motion detector
Yes
Yes
With integrated AI analysis
Yes
Yes
With integrated audio analysis
No
No
Number of ports 1000 Mbps Mini GBIC
0
0
Number of combination-ports RJ45/Mini GBIC
1
1
Number of ports PoE
0
0
Max. PoE power
0 W
0 W
Power over Ethernet (PoE)
None
None
With DVD
No
No
Redundant power supply
No
No
Power consumption
22 W
22 W
Max. recording resolution
8
8
Max. data transmission rate
1000
1000
Operating system
Linux
Linux
Number of pre-licensed cameras
16
16
RAID 0 capable
No
No
RAID 1 capable
No
No
RAID 5 capable
No
No
RAID 6 capable
No
No
RAID 10 capable
No
No
Hot-swappable hard disk capability
No
No
Width
268 mm
268 mm
Height
45 mm
45 mm
Depth
268 mm
268 mm
最小订单数量: 1 NR
条形码
8007352717572
1 NR
51x34.5x11.5 [cm]
3,376 [g]
