Passive video distributor on landing - 692D

Pdf
692D

ELVOX Door entry / Due Fili Plus / System components

Passive video distributor on landing
Passive floor distributor for adapting video signal impedance on balanced connection lines, installation on DIN rail (60715 TH35), occupies 1 module size 17.5 mm

产品状态
4 - Active

单, 说明书, 文档

Class group
Communication technique
Class
Mounting accessories for door communication
Suitable for
Indoor station
Material
Other
Mounting method
Surface mounted (plaster)
Colour
Other
最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8013406182159
1 NR
8x6x3.2 [cm]
70 [g]
Barcode Qty 20 NR
8013406306357
20 NR
40x18x11 [cm]
1,680 [g]
问题: When should I use the video distributor part no.692D?
回答: The distributors are used to create branches on the main backbone in the presence of multiple video intercom units. It is important to remember that on each secondary backbone (4 outputs per 692D) generated by the distributor, you shouldn't connect more than 2 monitors in series at a distance not exceeding 20 m.
