Vimar - EBM1 - KLYS9CD MASTER up&over operator 24V 9m2

EBM1

ELVOX Gates / Operators / Up-and-over

KLYS9CD MASTER up&over operator 24V 9m2
Non-reversible 24 V MASTER electromechanical operator for up-and-over doors up to 9 m2 in single operator configuration, or up to 12 m2 in conjunction with the KLYS 9CD SLAVE operator. Complete with electronic control card.

产品状态
42 - Will be discontinued

单, 说明书, 文档

Installer manual (5515 kb)

Class group
Gate operators, pumps and ventilators

Class
Garage door operator

Nominal voltage
24 v

Max. door/gate width
5.000 mm

Number of safety inputs
2

Frequency radio receiver
433 MHz

With rail runner
Yes

With interior push-button
Yes

Separate control unit housing
No

Soft run
Yes

Cycle counter
No

Door status indication
No

Defined running direction control
Yes

Connection for red traffic light
No

Suitable for collective garages
Yes

Floating relay output
No

With manual transmitter
No

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

条形码

8013406228215

1 NR

25x77x19.5 [cm]

11,500 [g]
