MASTER dimmer 230V spare part - R01870

Pdf
Vimar - R01870 - MASTER dimmer 230V spare part
Vimar - R01870 - MASTER dimmer 230V spare part

R01870
Smart systems&products / By-me Plus / Shared components / DIN devices

MASTER dimmer 230V spare part
Spare 230 V~ 50/60 Hz MASTER dimmer for 40-500 W incandescent lamps, 40-300 VA electronic transformers, 10-200 W CFL lamps, 3-200 W LED lamps, for LED electronic power supply units, protection fuse, installation on DIN rail (60715 TH35), occupies 4 modules size 17.5 mm

产品状态
3 - Active

Class group
Installation bus systems
Class
Dimming actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Dimming actuator
Mounting method
Other
Width in number of modular spacings
4
With bus connection
Yes
Bus module detachable
No
Local operation/hand operation
No
With LED indication
Yes
Number of outputs
1
Output power
40 - 500 W
Power boost suitable
No
Type of load
Universal and LED Retrofit
Voltage
230,00 - 230,01 V
Parallel-service possible
No
Frequency
50,00 - 60,00 HZ
Degree of protection (IP)
IP20

00. CE Marking - EU

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352648616
1 NR
11.7x10.8x7.1 [cm]
228.8 [g]
