Three push buttons+actuator - R14545

Pdf
Vimar - R14545 - Three push buttons+actuator
Vimar - R14545 - Three push buttons+actuator
R14545

Plana / Spare parts / Domotics - devices

Three push buttons+actuator
Spare control device with three simple push buttons and actuator with change-over relay output 8 A 120-230 V~, to be completed with 1 or 2 module interchangeable buttons - 3 modules

产品状态
3 - Active

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
3
Number of modules (module system)
3
Number of poles
1
Nominal voltage
230 v
Rated current
8,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Transparent
No
Label space/information surface
Yes
Imprint
None
Suitable for degree of protection (IP)
IP40
Width of device
67,30 mm
Height of device
49,00 mm
Depth of device
46,90 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352616868
1 NR
11.2x9.6x9.8 [cm]
155.71 [g]
