V54912
System infrastructure / Enclosures and control units / Floor mount turrets / Flush mounting
Box for screed for turret 12M
Flush mounting box for screed, for 12-module floor mounting turrets
产品状态
3 - Active
您可能也感兴趣
Class group
Subfloor electrical installation systems
Subfloor electrical installation systems
Class
Device installation insert for subfloor installation
Device installation insert for subfloor installation
Cover model
Rectangular
Rectangular
Number of inlets
8
8
Number of device cups
1
1
Number of socket outlets with protective contact CEE 7/3 (type F)
0
0
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 5P (1, 2, 3, N, PE)
0
0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 5P (1, 2, 3, N, PE)
0
0
Number of socket outlets British Standard BS 1363
0
0
With cable outlet in cover
Yes
Yes
Lockable cover
Yes
Yes
Housing material
Stainless steel
Stainless steel
Surface protection housing
Untreated
Untreated
Material cover
Stainless steel
Stainless steel
Surface protection cover
Untreated
Untreated
Surface treatment cover
Untreated
Untreated
Degree of protection (IP) when in use (cable outlet open)
Other
Other
Degree of protection (IP) when not in use (cable outlet closed)
Other
Other
Protective frame carpeting
Yes
Yes
Colour
Other
Other
Suitable for indoor installation
Yes
Yes
Suitable for outdoor installation
No
No
Suitable for subfloor duct
Yes
Yes
Suitable for hollow floor
No
No
Suitable for double floor built-in
Yes
Yes
Suitable for concrete installation
Yes
Yes
Suitable for floors in computer rooms
Yes
Yes
Suitable for wet cleaning
Yes
Yes
Outer width
310,00 mm
310,00 mm
Outer length
230,00 mm
230,00 mm
Length built-in dimension
230,00 mm
230,00 mm
Width built-in dimension
310,00 mm
310,00 mm
Min. built-in depth
105,00 mm
105,00 mm
00. CE Marking - EU
00. CE Marking - EU
最小订单数量: 1 NR
条形码
8007352735286
1 NR
32x24x13 [cm]
2,780 [g]
