IP55 junction box 380x300x120mm - V55110

Pdf
Vimar - V55110 - IP55 junction box 380x300x120mm
Vimar - V55110 - IP55 junction box 380x300x120mm

V55110
System infrastructure / Enclosures and control units / Junction boxes / Surface mounting

IP55 junction box 380x300x120mm
Surface mounting junction box with cable entries, cover closed with stainless steel screws, RAL 7035 grey. Supplied with two hinges. Dimensions 380x300x120 mm

产品状态
2 - Will be discontinued

Class group
Connection material (electrotechnical)
Class
Box/housing for surface mounting on the wall/ceiling
Max. conductor cross section
0
Equipped with
None
Shape
Rectangular
Mounting method
Wall-/ceiling mounting
Mounting in the soil
No
Mounting under water
No
For tube diameter
20/25 mm
Inlet from the rear
No
Length
380,00 mm
Width
334,00 mm
Depth
129,00 mm
Diameter
0 mm
Tackable
No
Number of inlets
12
Type of housing feed-through
Trimmable step membrane
Material
Plastic
Halogen free
No
Surface protection
Untreated
Colour
Grey
Degree of protection (IP)
IP55
Cover model
Blind cover
Transparent cover
No
Cover attachment
Screwed
Castable
No
With casting compound
No
Sealable
No
Rated insulation voltage Ui
450 V
Circuit integrity
None
With screening
No
Weatherproof
Yes
Operating temperature
0 - 60 °C
Explosion-tested version
No
For Ex-zone gas
None
For Ex-Zone dust
None

00. CE Marking - EU

01. IMQ - Italy

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 4 NR

条形码

Barcode Qty 1 NR
8007352079090
1 NR
33x41x12.9 [cm]
1,742 [g]
Barcode Qty 4 NR
8007352079106
4 NR
60x41.5x35.5 [cm]
7,968 [g]
